Internet Office UPS System - NAFTA assembled

version of the all-in-one SOHO solution

MODEL NUMBER: IO700NAFTA

Description

Tripp Lite's IO700NAFTA standby UPS system offers surge suppression and long-lasting battery support for

personal computers, internetworking equipment and other sensitive electronics. Internal UPS circuits support

Highlights

700VA tower UPS

Maintains 120V nominal output

during blackouts

Workstation optimized features

include USB port, single line TEL

/ DSL line surge suppression and

three surge-only outlets

Space saving right-angle input

plug

Input: NEMA 5-15P (120V 15A) /

Output: 6 NEMA 5-15R (120V)

$150,000 Ultimate Lifetime

Insurance (USA, Puerto Rico and

Canada only)

Package Includes

IO700NAFTA Standby UPS

System

USB and phone cable

Instruction manual with warranty

information

entry-level PC systems for up to 45 minutes during power failures and brownouts so that connected equipment

can be shut down without data loss. Offers complete desktop power protection in an attractive gray tower configuration. Includes 3 battery-supported outlets

for computer, monitor and one vital system peripheral, plus 3 additional surge suppression-only outlets for printers and other system accessories not requiring

battery support. HID-compliant USB port enables optional unattended system shutdown without data loss in the case of extended power failure; USB cable

included. HID compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. PowerAlert

software available via FREE download from es.tripplite.com. Built-in RJ45 TEL/Ethernet suppression jacks protect modem, fax machine, cordless phone or

other peripheral with a standard single-line tel/DSL or data line connection. Built-in audible alarm and 3 front panel LEDs indicate line power status, battery

power status and battery low/replace status. 700VA/425W power handling ability supports entry-level PCs, network workstations, point-of-sale equipment,

small business phone systems, audio/video equipment and home theater systems. Offers 3 min. battery runtime with a full load of 700VA and 11 min. with a

half load of 350VA. Supports user battery replacement via built-in access panel. $150,000 connected equipment insurance (USA and Canada Only).

Features

IO700NAFTA standby UPS system offers UPS battery support, plus complete AC and tel/DSL line surge suppression

Supports entry-level PC systems for up to 45 min. during brownouts and power failures to enable a safe system shutdown

Supports a max load of 700VA/425W for 3 min.

Supports a half load of 350VA/215W for 11 min.

Supplies battery-derived AC output during brownouts starting at 99V, user adjustment allows fine tuning of brownout response to any setting from 83V to

99V

Attractive gray tower configuration

Includes 3 battery-supported outlets plus 3 additional surge suppression-only outlets, and 6-ft. AC line cord (all NEMA 5-15)

HID-compliant USB port enables unattended shutdown without data loss during extended power failures; includes USB cable

HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

USB interface supports timed inverter shutoff after unattended shutdown
